Product Attributes

Model No.:

ZDM100

Type:

Polishing Machine Series

Application:

Polishing & Grinding & Sanding

Artificial Stone Type:

Artificial Marble

Automation:

Automatic

Control:

CNC

Certification:

ISO

Customized:

Customized

Color:

Yellow

Weight:

20T

MAX PROCESSING HEIGHT:

50MM

Dimension(L*W*H):

9600*3300*2400MM

Voltage:

380V/50Hz, Can Be Customized

Total Power:

200KW

Usage:

MARBLE POLISHING MACHINE

Supply Ability & Additional Informations

Payment Type:

L/C,T/T

Incoterm:

FOB,CFR,CIF,EXW

Transportation:

Ocean

Port:

QINGDAO,SHANGHAI,NINGBO

High Efficiency Marble Polishing Machine , Can be 12 heads, 16 heads, 20 heads, 24 heads.

1. Granite Stone Polisher Price surface for granite tiles,slab equipped with the resin disc special elastic polishing heads, polishing with more comprehensive,more efficient,lower abrasive wearing.

2.Using PLC system and liquid crystal display screen menu offer intelligent control.

3.Easy to operate.the working pressure,the beam travel speed and the belt advance speed can be adjusted according to the materials and the finishing gloss.

4.Establishing Auto-dodging function and shape-memory funtion,equiped with an advice to prevent the grinding hand from mistakenly hitting the belt,having high automation operation and low labor the strength.

5.Using the most advanced and high-quality construction,rational structure,high stabiity and efficiency,and energy saving operation.

6.Using central automatic lubrication system,so that all moving parts and bearings can get a good lubricating effect and longer life.

7.The power movement of polishing heads uses the narrow V belt with teeth set,to improved slabs flatness,reduced movement consumption and enhances the longer service life.

It is suitable for grinding and polishing slab.It is with logical construction;reliable performance;highly efficiency running.Control system is advanced, which adopts PLC control and with text display,which realizes intelligentize control.

It has the following features:

1.This machine is with pitch grinding disc bush which is with long life;  lower failure rate; higher efficiency,lower abrasive exhaustion rate,lower slab broken rate.

2.It uses transmission belt with the same thickness to confirm slab with the same thickness.

3.The moving speed of the transmission belt and penulation speed of transverse-beam can be adjusted by transducer.

4.This machine is with lower exhaustion power,lower cost;higher grinding and polishing efficiency;easy operation;maintenance simple.

ZDM100-6HEAD

Processing width                   300-1000mm

Processing thickness                  10-60mm

Grinding head quantity                   6pieces

Total power                             50.2kw

Grinding head motor power              6*7.5KW

Transmission-belt motor power            2.2kw

Transverse-beam pendulation motor         3kw

Transmission-speed for belt      0-2200mm/min

Compressor provide presssure      0.60-0.8Mpa

Cooling water pressure              ≥0.15Mpa

Water consumption of single-head    ≥25L/min

Total weight                           4900kgs

Installation size             3770*2430*2360mm

ZDM100-9HEAD

Processing width                     300-1000mm

Processing thickness                   10-60mm

Grinding head quantity                   9pieces

Total power                             72.7kw

Grinding head motor power              9*7.5KW

Transmission-belt motor power            2.2kw

Transverse-beam pendulation motor         3kw

Transmission-speed for belt      0-2200mm/min

Compressor provide presssure      0.60-0.8Mpa

Cooling water pressure              ≥0.15Mpa

Water consumption of single-head    ≥25L/min

Total weight                           5400kgs

Installation size             5150*2430*2360mm
